Honda EG5000

$1,999.00 $1,799.00

The EG5000 provides all the quality and reliability you expect from Honda, for budget-minded customers.

Categories: ,

Highlights –

  • AC Voltage Available – 120 / 240
  • Approximate Running Time (hrs.) / Tankful – 7.5** / 11****
  • Cold Climate Technology – Standard
  • Dry Weight – 77.5 kg (170.9 lbs.)

Features –

  • Economical, portable power with traditional Honda durability and performance
  • 5,000 watts maximum AC output
  • Reliable, easy-start Honda GX390 commercial-grade engine
  • Honda exclusive Digital Auto Voltage Regulator (DAVR) offers stable power delivery for increased performance
  • Voltage Selector Switch allows both 120 V and 240 V output, or total generator output to be available through any of the 120 volt outlets, limited only by the capacity of the individual outlet for powering devices with larger wattage requirements.
  • 11 hour continuous running time at 50% load with large 24-litre tank
  • Cold Climate TechnologyTM aids continuous running in cold weather conditions
Generator Type
Brush type
Maximum AC Output (Watts)
5,000
AC Voltage Available
120 / 240
Maximum Continuous AC Output (Watts)
4,500
Max. Rated AC Amperage @ 120 V / 240 V
37.5 / 18.8
Ground Fault Circuit Interrupter (GFCI)
N/A
Frequency (Hertz)
60
Automatic Voltage Regulator
Standard digital (DAVR)
DC Output Volts / Amps
N/A
Common Duplex Receptacle Specifications
37.5 amps/120 VAC continuous is available as combined total from these two AC receptacles. Maximum of 18.8 amps available from each single receptacle.
DC Receptacle Specifications
N/A
DC Charging Cable
N/A
High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications
This receptacle will supply 30 amps at 120 VAC continuously. This receptacle will supply 18.8 amps at 240 VAC and 37.5 amps at 120 VAC continuously.
Engine Type
Honda GX390T2 OHV, 4-stroke, air-cooled
Displacement
389 cc
Starting System
Manual recoil
Low Level Oil Alert System
Standard
Auto Throttle
N/A
Remote Start Capability
No
Fuel Tank Capacity
24 litres (5.28 Imp. gal.)
Transport Wheels
Optional (P/N 06710-Z22-A40ZA)
Lifting Hook
Optional (P/N 06810-Z22-A30ZA)
Battery
N/A
Approximate Running Time (hrs.) / Tankful
7.5** / 11****
Rated Fuel Consumption (litres/hr)
3.22**
Noise Level dB(A) (1.5 m to 7 m)
73**
Length (Without Handles and Wheels)
681 mm (26.8 in.)
Length (With Handles and Wheels)
N/A
Width (Without Handles and Wheels)
530 mm (20.9 in.)
Width (With Handles and Wheels)
N/A
Height (Without Lift-Hook)
571 mm (22.5 in.)
Height (With Lift-Hook)
N/A
Dry Weight
77.5 kg (170.9 lbs.)
Cold Climate Technology
Standard
** / ***
**At max. rated output (continuous) in Watts.
****At 50% rated output (continuous) in Watts.
