Honda FG110K1C

Honda UMC425CLACT

$329.00

The Honda VersAttach^TM Powerhead is the ultimate yard work companion, switching between attachments to suit your landscaping needs

Categories: Honda, Honda Powerhead, Landscaping Equipment & Tools

Description
Reviews (0)

Highlights –

Power / Displacement – 25 cm³
Starter – Easy start
Handle Type – Loop
Weight – 5.1 kg (11.2 lbs)

Features –

Powered by 25 cc Honda GX25 OHC Mini 4-stroke engine
Fuel efficient, user-friendly and easy to start
Offers full 360º inclinable operation
Safe and secure SureLoc^TM System – easy to connect
Wide variety of multi-purpose attachments available
Compact and lightweight ergonomic design
Low engine noise and minimal vibration

Specifications –

Engine

Engine Type: Honda GX25, mini 4-stroke, OHC, single cylinder air-cooled multi-position (360°)

Honda Engine Model: GX25T

Displacement: 25 cc (1.53 CID)

Bore & Stroke: 35 x 26 mm (1.4 x 1 in.)

Maximum Net Torque: 1.0 N.m (0.74 lbf-ft.) @ 5,000 RPM

Idle Speed: 3,100 ± 200 RPM

Max. No-Load RPM: 10,000 RPM

Ignition System: Transistorized magneto ignition (electronic)

Spark Plug: CMR5H (NGK)

Cooling System: Forced air

Starting System: Recoil starter

Stopping System: Ignition primary circuit ground

Carburetor: Diaphragm type w/ fuel pump

Recommended Fuel: Regular unleaded gasoline (86 Octane or higher)

Fuel Capacity: 0.53 L (18.7 fl. Imp. oz.)

Clutch Drive Type: Centrifugal Twin Shoe-Clutch

Clutch Size: 54 mm (2.125 in.) Diameter

Clutch Engagement: 4;200 ± 200 RPM

Air Cleaner: Semi-dry type

Lubrication System: Oil mist

Oil Capacity: 80 cc (2.82 fl. Imp. oz.)

Recommended Oil: SAE 10W30 API service classification SJ or later

Product Dimensions

Overall Length (without attachment): 113.5 cm (44.7 in.)

Overall Width: 31.5 cm (12.4 in.)

Overall Height: 24.5 cm (9.6 in.)

Dry Weight (without attachment): 5.1 kg (11.2 lbs.)

Additional Information

Handle Type: Loop

Throttle Control Type: Two-motion trigger type

Engine Stop Switch: Slide type switch

Drive Shaft Type: Rigid Steel

Shaft Support: Rubber Mounted Bushings (4)

Main Pipe Diameter: 24 mm (0.94 in.)

Main Pipe Thickness / Material: 2 mm (0.08 in.) Aluminum

Shoulder Harness: Standard

Safety Goggles (A.N.S.I Std.): Standard

Blade Barrier Kit: Standard
