Description
- Dual-stage, wheel drive, 71 cm (28 in.) clearing width
- Clear up to 52 metric tons (up to 57 tons) of snow per hour† and throw it up to 16 metres (52.5 ft.)†
- Infinitely variable hydrostatic drive system provides convenient and intuitive operation with optimum control.
- 15" wheels with 2 ply directional tires
- Remote electric chute with “joystick" control (Battery-less)
- Powerful LED headlight
- Built-in icing guard design prevents icing in the carburetor and provides better access to the carburetor drain bolt and fuel cut-off lever
- Low noise muffler with guard
- Discharge Type
- Dual-stage
- Axle Type
- Wheel drive
- Drive Type
- Hydrostatic transmission (HST) with Steering Assist Drive System
- Transmission Oil Capacity
- 1.94 – 1.97 L (68.3 – 69.3 fl. Imp. oz.)
- Hydrostatic Transmission
- SAE 5W30 API service classification SJ or later
- Speeds
- Infinitely variable
- Clearing Width
- 71.0 cm (28 in.)
- Maximum Ground Speed
- Forward: 84 m/min. (275.6 ft./min)
Reverse: 48 m/min. (157.5 ft./min)
- Intake Housing Height
- 55.0 cm (21.7 in.)
- Auger Diameter
- 35.5 cm (14 in.)
- Auger Type
- Steel serrated (Spiral)
- Auger Drive
- Belt driven shaft
- Auger Transmission
- Screw gear
- Auger Oil Capacity
- 0.16 L (5.6 fl. Imp. oz.)
- Auger gear box
- SAE 75W90 GL-5
- Auger Height Adjustment
- Skid shoes
- Chute Turning Radius
- 198 ° (95° Left, 103° Right)
- Chute Rotation
- Remote electric “Joystick” control
- Deflection Control
- Remote electric “Joystick” control
- Chute Material
- Steel
- Maximum Throw Distance†
- 16 m (52.5 ft.)
- Clearing Snow Volume Capacity (Approximate)†
- Up to 52 metric tons/hr (57 tons/hr)
- Engine Type
- Honda GX270T2, 4-stroke, OHV, single-cylinder
- Displacement
- 270 cc (16.5 CID)
- Ignition System
- CDI magneto
- Recoil Starter
- Standard
- Electric Starter
- N/A
- Lubrication System
- Forced splash
- Oil Capacity
- 1.1 L (38.7 fl. Imp. oz.)
- Oil for engine
- SAE 5W30 API service classification SJ or later
- Recommended Fuel
- Unleaded gasoline (Pump octane rating 86 or higher)
- Fuel Tank Capacity
- 5.3 L (1.17 Imp. gal.)
- Operational Time per Tankful*
- 2.3 hours
- Wheel/Tire Size
- 15 x 5.00 – 6 (2 ply) tubeless/directional
- Overall Length
- 148.5 cm (58.5 in.)
- Overall Width
- 77.5 cm (30.5 in.)
- Overall Height
- 110.5 cm (43.5 in.)
- Dry Weight
- 105 kg (231.5 lbs.)
- Lighting Coil
- Standard
- Work Light
- Standard (type LED)
- Distributor’s Warranty (non-commercial use)
- 36-month
- Distributor’s Warranty (commercial use)
- 36-month
